现场铣削提升机滚筒衬板绳槽装置(含CAD零件图装配图)

现场铣削提升机滚筒衬板绳槽装置(含CAD零件图装配图)(开题报告,中期检查表,外文翻译,论文说明书13000字,CAD图7张)
摘要
矿山提升设备是矿山运输中的咽喉设备，占有特殊地位，是井下与地面联系的主要工具。提升机是用来将矿物运出矿井的设备。本文详细介绍了JTP—1.6×1.2型提升绞车的卷筒车绳槽装置，核心部件“车槽装置”的重要工作原理及其设计思想、方法、步骤、工作的全过程。对车槽装置与滚筒的连接方式、丝杠的支承方式、轴承的选用、螺母及丝杠等部件进行设计。
针对提升绞车的工作范围及已知条件进行分析，设计出一套卷筒车绳槽装置，这种装置结构简单，操作方便，绳槽深度的间距控制比较准确。也可以减少因绳槽加工不合理而出弦的咬绳和断绳的发生几率，是钢丝绳井然有序的排列在滚筒上。

关键词：提升绞车  滚筒  丝杠  轴承  导轨

Abstract
Mine hoisting equipment is mine in transportation of throat equipment, special status, is the underground and surface contact of the main tools. Lift machine is used to convert the minerals out of the device. This article details the JTP - 1. 6 × 1.2-winch drum car Groove device, core components of the grooves device "important works and design ideas, methods, procedures, work in process. On grooves and drum connection, screw the support, selection of bearings, nuts and screws, etc.
For the operating range of the hoist and known conditions for analysis, design a reel cart Groove device, the device structure is simple, easy to operate, Groove depth of spacing control more accurate. You can also reduce the Groove processing is not reasonable and squid industry SAC ® and rope incidence is rope uncluttered arranged in drum.

Key words: drum hoist  bearing ball  screw   Guide
