电动剃须刀盒盖塑件的注射模具设计(含CAD零件装配图)

电动剃须刀盒盖塑件的注射模具设计(含CAD零件装配图)(任务书,开题报告,外文翻译,论文说明书12000字,CAD图纸10张)
毕业设计说明书（论文）中文摘要
本文主要介绍电动剃须刀盒盖的注射模具设计，电动剃须刀盒盖是电动剃须刀装置中的一个塑料组件，其材料为ABS塑料，根据ABS塑料成型的工艺特性和产品的使用要求，对产品进行详细的工艺分析。通过对测绘的产品尺寸和工艺分析，选择了合适的分型面，对模具进行了成型零件、浇注系统、镶块镶拼结构及推出机构和复位机构进行设计，最后完成一副模具总装图的设计及主要零件图的绘制，并确保模具结构的可靠性、合理性、实用性。
     在模具设计过程中，采用了UG、Pro/ENGINEER、AutoCAD等著名的设计分析软件，采用这些软件进行设计分析，优化了设计的参数和缩短了设计时间，提高了设计效率。

关键词  电动剃须刀盒盖 模具设计 ABS塑料

毕业设计说明书（论文）外文摘要
Title    Research on thermal stress, deformation, and fatigue lifetime of the rapid heating cycle injection mold
Abstract
Rapid heating cycle molding (RHCM) is a novel plastic injection molding process. It can be used effectively to prevent many defects of products produced in conventional injection molding process. In this paper, the panel of large-size liquid crystal display TV was taken as an example. Thermal, deformation, and fatigue analysis models for RHCM injection mold were established. Firstly, by analyzing the heat transfer process of the RHCM mold, the temperature distributions on the mold cavity surface were studied. Secondly, through numerical simulation, the tendency of the stress and deformation of the RHCM mold was obtained. It showed that the fixing mode between the  stationary mold insert and the stationary mold plate had a great influence on the thermal stress and deformation of the mold. As a result, a new fixing mode for the stationary mold insert was proposed which could effectively decrease the deformation caused by the temperature changing. Lastly, the lifetime of the mold under different fixing  modes was evaluated, and reasonable suggestions which could improve the lifetime of RHCM mold were also proposed. Application in engineering proved that it was a very effective way to improve the lifetime of RHCM mold by using the suggested fixing mode.

Keyword  Rapid heating cycle molding .Numerical simulation . Heat transfer . Thermal fatigue


目   录
前  言    1
第一章 塑料产品介绍及其工艺特点    4
    1.1产品结构工艺性分析    4
1.1.1塑料的分析    5
1.1.2 塑件的工艺分析    6
1.2 塑件产品图的测绘    6
    第二章 注射成型方案分析    8
    2.1分型面及其选择    8
    2.1.1塑料制件在模具中的位置    8
    2.2浇注系统分析    9
    第三章 模具的结构设计    10
    3.1模架的选择    10
    3.2 塑件的成型设备选用    11
    3.2.1分型面投影面积的计算    11
    3.2.2塑件及浇注系统的体积的计算    11
    3.2.3注塑机的选择    12
    3.3成型零部件设计    13
    3.3.1成型零部件的结构设计    13
    3.3.2成型零部件的工作尺寸计算    13
    3.4浇注系统的设计    23
    3.4.1主流道的设计    23
    3.4.2浇口的设计    25
    3.5推出机构的设计    26
    3.5.1推出力的计算    26
    3.5.2推出机构的选择    27
    3.6复位机构的设计    27
    3.7冷却系统的设计    27
    第四章 注塑机的选择与校核    28
    4.1注塑量的校核    28
    4.2注塑机锁模力的校核    28
    4.3最大注射压力的校核    28
    4.4开模行程及装模高度的校核    28
    第五章 模具的工作原理和模具结构特点    29
    5.1模具工作原理    29
    5.2模具结构特点    30
结论    31
致谢    32
参考文献    33
